Semi Automatic Strapping Machine

Semi Automatic PP Straping Machine Features

A semi-automatic PP strapping machine is a cost-effective and user-friendly solution for bundling packages using polypropylene (PP) straps. Here are its key features:

Semi-Automatic Operation

  • Requires manual placement of the strap around the package
  • Machine tightens, seals, and cuts the strap automatically.

    • Adjustable Strap Tension

  • Tension can be adjusted based on the package size and material.
  • Typically ranges from 10 kg to 70 kg.

    • Compact & Portable Design

  • Smaller and lighter compared to fully automatic models.
  • Often equipped with wheels for easy mobility.

    • Compatibility with Various Strap Sizes

  • Supports 6mm, 9mm, 12mm, or 15mm wide polypropylene straps.
  • Quick and easy strap width adjustment.

    • Efficient Sealing Mechanism

  • Uses heat-sealing technology for strong and secure strap joints.
  • Fast heating system for quick operation.

    • User-Friendly Controls

  • Simple control panel with adjustable tension, sealing time, and operation mode.
  • Can be operated with a foot pedal or push button.

    • High-Speed Performance

  • Can strap 15 to 30 packages per minute, depending on operator efficiency.

    • Power-Efficient Operation

  • Low power consumption, typically around 250W - 750W.
  • Auto shut-off feature to save energy when not in use.

    • Durable & Low Maintenance

  • Built with a sturdy metal frame for long-term use.
  • Requires minimal maintenance compared to fully automatic models.

    • Safety Features

  • Overheating protection to prevent damage.
  • Emergency stop button for added safety.

    • Semi Automaitc PP Strapping Machine Specifications

    Machine Dimensions & Weight

    • Machine Size: Approx. L 900mm × W 580mm × H 750mm (varies by model)
    • Weight: 80-120 kg, depending on the build and features

    Strapping Speed

    • 15 to 30 straps per minute, depending on operator efficiency

    Strap Compatibility

    Strap Material

    Polypropylene (PP)

    Strap Width

    6mm, 9mm, 12mm, or 15mm (adjustable)

    Strap Thickness

    0.5mm – 1.2mm

    Strap Core Size

    200mm / 230mm / 280mm (varies by model)

    Strap Tension

    Adjustable, typically 10-70 kg

    Sealing Method

    • Heat-sealing (hot-melt welding)

    Package Size Compatibility

    • Minimum Package Size:Approx. W 100mm × H 30mm
    • Maximum Package Size:No specific limit, as long as the strap can be manually placed

    Power Supply

    • Voltage: AC 220V / 50Hz (single-phase) or 110V / 60Hz (varies by model)
    • Power Consumption: 250W - 750W

    Working Table Height

    • Approx. 750mm - 800mm

    Control System

    • Simple control panel with tension adjustment, sealing time, and cycle start options
    • Operated using a foot pedal or push button

    Safety Features

    • Overheating protection
    • Auto shut-off feature when idle
    • Emergency stop button

    Build & Design

    • Sturdy stainless steel or powder-coated metal body
    • Portable with caster wheels for easy movement
